Product Details:
|
| Product Name: | Silicone Coated Release Liner For Self-adhesive Waterproof Membranes | Material: | HDPE |
|---|---|---|---|
| Thickness: | 0.03-0.15mm | Width: | 100-2000mm |
| Application: | Used For Waterproofing Membranes, Adhesive Tapes,etc. | Color: | Black, Grey, White, Blue, Green, Etc. |
| Performance: | One Or Two Sided Silicone Coated | Process: | Three-layers Blowing |
| Highlight: | Self Adhesive Silicone Release Liner,Waterproof Membranes Silicone Release Liner,HDPE Silicone Release Liner |
||
Silicone coated release liner refers to the film with separative film on the surface.
Silicone coated on either one sided or two sided. The carrier can be PE films, PP films,
PET films and Papers. It will be peeled off when use the self-adhesive products,
such as bitumen waterproof membranes, PVC floor, butyl tapes and other products.
Parameter:
| Products Name | PE release film | Spec. | 0.05mm*530mm | ||
| Detection Method | Q/TPXP 1-2013 | Date | 2021.4.21 | ||
| NO. | Item | Factory Requirement | Detection Value | Individual Determination | |
| 1 | Appearance | No bubbles, no stains, no damage, no impurities | Qualified | Qualified | |
| 2 | Spec. | Width | 530±10mm | 531 | Qualified |
| Thickness | 0.05±0.005mm | 0.051 | Qualified | ||
| 3 |
Max.F (N/50mm) |
TD (CD) |
≥30 | 50 | Qualified |
| MD | ≥30 | 68 | Qualified | ||
| 4 |
Elongation (%) |
TD (CD) |
≥150 | 692 | Qualified |
| MD | ≥200 | 521 | Qualified | ||
| 5 |
Release Force (N/25mm) |
3-8g | 7 | Qualified | |
| 6 | Subsequent Adhesion (%) |
≥90 | 94 | Qualified | |
| Detection | Qualified | ||||
Advantages:
| 1. Easy to construction |
| 2. Low release force, easy peel off when remove the release film |
| 3. High residual adhesiveness rate(≥90%) to prevent the influence of silicon transfer on products |
| 4. Environmental Production technology of solvent and solvent-free products |
| 5. Environmentally Friendly. Can be recycling |
| 6. High tear resistance than PP and PET films |
Applications:
Butyl Tapes:
Partners:
