Product Details:
|
| Product Name: | Butyl Tapes Application Temperature Resistance Anti Corrosion Film | Material: | Fluorine Film+ Cross Laminated Film |
|---|---|---|---|
| Production Process: | Film Blowing And Laminated | Performance: | Aging Resistance |
| Thickness: | 0.09-0.15mm | Width: | 100-1250mm |
| Color: | White, Green, Black, Etc. | Application: | Tapes, Waterproofing Membranes |
| Printing: | Can Be Customizable | Sample: | Available |
| Highlight: | Butyl Tapes Anti Corrosion Film,0.15mm Anti Corrosion Film,ROHS Laminated Anti Corrosion Film |
||
Butyl Tapes Application Temperature Resistance Anti Corrosion Film
Description:
|
It is specially designed for waterproofing industries, tapes industries which shall substitute conventional exposed waterproofing material including the film for waterproofing membranes and butyl tapes, weather resistance tapes and so on. It also has cost effectiveness, and lasts over 25years of weather resistance. |
Application:
| It is used as surface material for self-adhesive tapes, self-adhesive waterproofing membranes and other weather resistance products. |
Weather Resistance Tapes Application:
Aging Resistance Waterproof Membranes Application:
Advantages:
| 1. Excellent properties of anti-aging | |||
| 2. UV resistance | |||
3. Weather resistance
7. High strength, tear resistance |
Parameter:
| Detection Item | Detection Method | Detection Value | Remark | |
| Thickness | UF509 | GB/T6672-2001 | 0.128mm | / |
| Width | GB/T6673-2001 | / | According to customer needs | |
| Max force | UF509 | GB/T 328.9-2007 | MD:324N | Rectangular spline, spline width 25mm, stretching rate: 100mm / min, fixture gauge distance: 100mm |
| TD:348N | ||||
| Elongation at Break | UF509 | MD:406% | ||
| TD:260% | ||||
| Tensile Strength | UF509 | GB/T 529-2008 | MD:47N | Stretching speed:250mm/min |
| TD:43N | ||||
| Surface Tension | GB/T14216 | ≧42dyn/cm | Dyne Pen Test | |
| Dimensional change rate | UF509 | GB/T 35467-2017 | MD:0.96% | 90℃&24h |
| TD:0.77% | ||||
| Water vapor transmission rate | GB/T 21529 | ≦70 g/m2.24h (20um) | 38℃+100%RH | |
| Electrolytic sensor method | ||||
| Flammability grade | UL94 | VTM-0 | White weathering film | |
| Aging test | PCT96 | / | Yellowing index △b≤2.0, | Temperature 121 ℃, humidity 100%, air pressure 2atm, time 48h |
| UV300KWh | IEC61215 | The temperature of the sample is 60 ± 5 ℃, and the total exposure is 120KWh • m2, of which UVB accounts for 3% -10%. | ||
| DH2000h | IEC61215 | Temperature 85 ℃, humidity 85% R.H., 2000h | ||
| TC400 | IEC61215 | Temperature －40 ℃ ～ 85 ℃, 6h / cycle, 400cycle | ||
